2023 Mesa Ridge Fifth Wheels | 376FBH
2023 Mesa Ridge Fifth Wheels
Previous model years are dealer stock only.
See Floorplan with
an Option Added:
See Floorplan with
Interior Design
Graystone
Specifications
Weights
| Dry Hitch Weight (lbs) | 2,515 |
| Unloaded Vehicle Weight (lbs) | 12,240 |
| Cargo Carrying Capacity (lbs) | 2,760 |
| Gross Vehicle Weight Rating (lbs) | 15,000 |
Measurements
| Exterior Length (overall) | 42' 3" |
| Exterior Length (pin to bumper) | 40' 8" |
| Exterior Height | 12' 8" |
| Exterior Height (with A/C) | 13' 2" |
| Exterior Width | 8' 4" |
| Exterior Width (with slides out) | 13' 9" |
| Interior Height (main) | 8' 2" |
| Interior Height (upper deck) | 6' 4" |
| Awning Length | 19' 0" |
Tank Capacities
| Fresh Water Capacity (gals) | 75.0 |
| Gray Water Capacity (gals) | 82.0 |
| Black Tank Capacity (gals) | 82.0 |
| Propane Unit (lbs) | 60 |
Miscellaneous
| Sleeps | up to 8 |
| Water Heater | 10 |
| # of outside storage compartments | 5 |
| Furnace BTU | 40000 |
| Tire Size | ST235/85R16'F |
