2024 Open Range Conventional | 233TH
2024 Open Range Conventional
Specifications
Weights
| Dry Hitch Weight (lbs) | 915 |
| Unloaded Vehicle Weight (lbs) | 4,980 |
| Cargo Carrying Capacity (lbs) | 2,040 |
| Gross Vehicle Weight Rating (lbs) | 7,600 |
Measurements
| Exterior Length (overall) | 28' 4" |
| Exterior Length (pin to bumper) | 25' 3" |
| Exterior Height | 9' 9" |
| Exterior Height (with A/C) | 10' 6" |
| Exterior Width | 8' 0" |
| Interior Height (main) | 6' 9" |
| Awning Length | 16' 0" |
| Garage Length | 11' 10" |
Tank Capacities
| Fresh Water Capacity (gals) | 42.0 |
| Gray Water Capacity (gals) | 39.0 |
| Black Tank Capacity (gals) | 39.0 |
| Propane Unit (lbs) | 60 |
| Furnace, Auto-ignition (BTU output) | 25000 |
Miscellaneous
| Sleeps | up to 6 |
| Water Heater | 6 |
| # of outside storage compartments | 2 |
| Tire Size | ST205/75R14'D' |
2023 Specs Shown
Standard Features and Options
